25 STORM 120 29 GREY

The Storm 120 is designed with a progressive off-road design and features that will inspire you to discover your favorite way to ride. One standout feature is the inclusion of a dropper seat post for added convenience and control.

Specifications

Frame

• Aluminum, Smooth Welding, Tapered HT

Fork

• SR Suntour XCM32LO with lockout
• 120mm travel, 46mm offset
• 15x110mm Boost

Headset

• Sealed Cartridge Bearings
• Tapered 1-1/8" - 1.5" (IS42/28.6 | IS52/40)

Cockpit

• Grips: DDK Lock-On, 139mm length
• Handlebar: 6061 Alloy DB, 750mm (S) / 780mm (M, L, XL, XXL), 30mm rise
• Stem: Alloy, 50mm length, 31.8mm clamp

Seat Post and Saddle

• Seat Post: X-Fusion Manic LC, 31.6mm
  • 100mm (S)
  • 125mm (M, L, XL, XXL)
• Saddle: Norco XC, Steel Rail

Brakes

• Front Brake: Tektro HD-M275, Resin pads
• Rear Brake: Tektro HD-M275, Resin pads
• Brake Rotors: Tektro 160mm rotors, 6-bolt
• Brake Levers: Tektro HD-M275

Drivetrain

• Shifter Rear: Shimano Cues SL-U6000-10R, 10-speed
• Rear Derailleur: Shimano Cues RD-U6000, GS, 10-speed
• Cassette: Shimano Cues CS-LG300-10, 11-48T, 10-speed
• Chain: KMC Z10
• Crankset: Prowheel Alloy, 30T
  • 170mm (S-M)
  • 175mm (L-XXL)
• Bottom Bracket: Cartridge, ST 73mm, 113mm axle length

Wheels and Tires

• Front Hub: Formula DC51, 15x100mm Boost, 32h, 6-bolt
• Rear Hub: Formula DC-1422, 10x135mm QR, HG, 32h, 6-bolt
• Spokes/Nipples: Stainless Steel, 14g
• Rims: WTB STi25, 25mm ID, 32H, Tubeless compatible
• Front Tire: Maxxis Ardent, 29x2.4" (27.5x2.4" for S), Wire
• Rear Tire: Maxxis Ardent Race, 29x2.2" (27.5x2.2" for S), Wire

With its carefully selected components and thoughtful design, the Storm 120 is built to handle off-road adventures with confidence and style.
